CPU |
ARM 9, 32 bit RISC |
RAM |
256MB |
Flash |
16MB |
Video Input |
1/3.2 "CMOS (2 Megapixels) |
Minimum illumination |
0 lux (IR On) |
Support DC IRIS |
Yes |
Lens Type |
Vari-focal 3.6 ~ 16mm, F1.2 |
Viewing Angle |
20.8 ° ~ 75.4 ° (horizontal) 15.7 ° ~ 54.9 ° (vertical) |
ICR |
Mechanism IR cut Filter |
LED |
Built-in 35 IR LED |
IR Distance 20M |
Alarm input / output |
1 in / 1 Relay Out |
Video output |
1.0Vp-p, 75?, BNC |
Audio |
G.711 audio compression Interface: Mic in Audio output: 3.5mm phone jack Support 2-way audio |
Power supply |
Power 12V DC Power Consumption: IR on 6.5W, IR off 4.8W PoE Class 0 (IEEE802.3af), optional / Power Consumption: IR on 9.3W, IR off 6.9W |
Operating temperature |
-10 ° C ~ 40 ° C |
Size |
83mm (Ø) x 180mm (D) |
Weight |
1000g |
Network
|
Ethernet |
10/100 Base-T |
Network Protocols |
HTTP, TCP / IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, 3GPP, SAMBA |
System
|
Image resolution |
1600x1200, 1280x1024, 1280x960, 1280x720, 800x600, 640x480, 320x240, 176x144 |
Image Adjustment |
Brightness, Contrast, Sharpness, BLC, Night Mode |
Simultaneous transmission of three-mode video streaming |
Yes |
Image capture |
Yes |
Full Screen |
Yes |
Privacy Mask |
Yes, 3 different areas |
Image image compression format |
H.264 / JPEG / MPEG4 (3GPP only) |
Adjust the image transmission bit rate |
CBR, VBR |
Motion Detection |
Yes, 3 different areas |
Trigger event |
Mail, FTP, Save to SD card, Relay, Samba |
Pre / post alarm |
Yes, configurable |
Security |
Password protection |
Firmware Update |
HTTP mode, can be upgraded remotely |
Most users connections |
Up to 10 |
Client System Requirements
|
Operating system |
Windows 2000, XP, 2003, Microsoft IE 6.0 or above |
Hardware |
Proposal |
Intel Dual Core 1.66G, RAM: 1024MB, Graphic card: 128MB |
Minimum requirements |
Intel-C 2.8G, RAM: 512MB, Graphic card: 64MB |
|
